Integrated Peripherals
Figure 9: Integrated Peripherals
••••
Onboard FDC
Auto Auto detect OnBoard Floppy disk controller. (Default
value)
Enabled Enable OnBoard Floppy disk controller.
Disabled Disable OnBoard Floppy disk controller.
•
On Board Serial Port 1
Auto BIOS will automatically setup the port 1 address.
(Default Value)
3F8/COM1 Enable on Board Serial port 1 and address is 3F8.
2F8/COM2 Enable on Board Serial port 1 and address is 2F8.
3E8/COM3 Enable on Board Serial port 1 and address is 3E8.
2E8/COM4 Enable on Board Serial port 1 and address is 2E8.
Disabled Disable on Board Serial port 1.
•
OnBoard Parallel port
378 Enable On Board LPT port and address to 378.
278 Enable On Board LPT port and address to 278.
3BC Enable On Board LPT port and address to 3BC.
Auto Set On Board LPT port to Auto. (Default Value)
Disabled Disable On Board LPT port.
•
Parallel Port Mode
EPP Using Parallel port as Enhanced Parallel Port. (Default
Value)
ECP Using Parallel port as Extended Capabilities Port.
Normal Normal Operation.
EPP+EC
P Using Parallel port as Enhanced Parallel Port & Extended
Capabilities Port.
••••
Parallel Port DMA
N/A Disable this function. (Default Value)
Auto Set Auto to parallel port mode DMA Channel.
3 Set Parallel Port DMA to 3.
1 Set Parallel Port DMA to 1.
0 Set Parallel Port DMA to 0.
AMIBIOS SETUP – INTEGRATED PERIPHERALS
( C ) 1999 American Megatrends, Inc. All Rights Reserved
OnBoard FDC Auto
OnBoard Serial Port 1 Auto
OnBoard Parallel Port Auto
Parallel Port Mode EPP
Parallel Port DMA N/A
Parallel Port IRQ Auto
OnBoard IDE Both
OnBoard AC’97 Audio Auto
OnBoard MC’97 Modem Auto
MPU-401 Disabled
MPU-401 I/O Address 330h-333h
ESC: Quit ↑↓→ ← : Select Item
F1 : Help PU/PD+/-/ : Modify
F5 :Old Values (Shift)F2:Color
F6 : Load BIOS Defaults
F7 : Load SETUP Defaults
