7ZMMC Motherboard
15
••••
User password
Change, set, or disable password. It allows you to limit access to the system.
••••
IDE HDD auto detection
Automatically configure hard disk parameters.
••••
Save & Exit Setup
Save CMOS value settings to CMOS and exit setup.
••••
Exit Without Saving
Abandon all CMOS value changes and exit setup.
Standard CMOS Setup
The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no,
one or more than one setup items. Use the arrows to highlight the item and then use the
to select the value you want in each item.
Figure 2: Standard CMOS Setup
••••
Date
The date format is
Week
The week, from Sun to Sat, determined by the BIOS and is
display-only
Month
The month, Jan. Through Dec.
Day
The day, from 1 to 31 (or the maximum allowed in the month)
Year
The year, from 1990 through 2099
••••
Time
The times format in
clock. For example, 1 p.m. is 13:00:00.
••••
Primary Master, Slave / Secondary Master, Slave
The category identifies the types of hard disk from drive C to F that has been installed in the computer. There
are two types: auto type, and user definable type. User type is user-definable; Auto type which will
automatically detect HDD type.
Note that the specifications of your drive must match with the drive table. The hard disk will not work properly
if you enter improper information for this category.
AMIBIOS SETUP – STANDARD CMOS SETUP
( C ) 1999 American Megatrends, Inc. All Rights Reserved
Date (mm/dd/yyyy) : Tue Jan 25, 2000
Time (hh/mm/ss) : 10:36:24
TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE
Pri Master : Auto
Pri Slave : Auto
Sec Master : Auto
Sec Slave : Auto
Floppy Drive A: 1.44 MB 3 ½
Floppy Drive B: Not Installed
Boot Sector Virus Protection : Disabled
Base Memory : 640 Kb
Other Memory: 384 Kb
Extended Memory: 30Mb
Total Memory: 31Mb
Month: Jan – Dec ESC : Exit
Day: 01 – 31
↑↓
: Select Item
Year : 1990– 2099 PU/PD/+/– : Modify
(Shift)F2 : Color
