Team Associated RC8.2 - Manual (Page 8)

8
:: Center Differential Assembly - Bag C
:: Center Differential Assembly (cont.) - Bag C
:: Center Differential Assembly (cont.) - Bag C
Align pin with
groove in sun gear
!
89120
Sun gear
89115
Diff
housing
25236
8x16mm
bearing
89121
Diff
O-Ring
89119
Diff
outdrives
(center)
89120
Diff
washer
x2
89121
Diff
O-Ring
89495
Light spur
gear
(44T)
89119
Diff
outdrives
(center)
25236
8x16mm
bearing
89121
Diff
O-Ring
#6588
black grease
#6588
black grease
#6588
black grease
89120
Diff
outdrive
pin
89120
Spider
gear
assembly
