Team Associated RC8.2 - Manual (Page 27)

27
:: Radio Tray Assembly (cont.) - Bag K
:: Radio Tray Assembly (cont.) - Bag K
89078
Servo link
rod end
89454
3x12mm
shcs
89471
Forward
battery box
(top)
25215
M3
locknut
2308
3x18mm
bhcs
89078
ball
joint
89267
32mm steel
turnbuckle
25201
3x8mm
fhcs
89007
Servo
horn ring
89007
Steering
servo horn
89214
4x12mm
fhcs
89471
Forward
battery box
foam pad
(top)
89471
Forward
battery box
foam pad
(bottom)
x2
x2
x2
89471
Forward
battery box
(bottom)
89007
Servo cone
washer
25187
3x14mm
bhcs
Insert the receiver
battery wire into
the receiver box!
Enlarge holes
in servo horn!
!
!
!
Wire routing diagram
!
7mm
A - Airtronics
F - Futaba
H - Hitec
J - JR
Printed here
!
#1596
thread lock
