Team Associated RC8.2 - Manual (Page 28)

28
:: Radio Tray Assembly (cont.) - Bag K
:: Radio Tray Assembly (cont.) - Bag K
:: Radio Tray Assembly (cont.) - Bag K
A - Airtronics
F - Futaba
H - Hitec
J - JR
Printed here
Enlarge holes
in servo horn!
When adjusting
linkage, it may
be necessary to
change hole loca-
tion for correct
alignment with
carburetor
!
!
!
!
89126
Brake link
25225
3x3mm
setscrew
89008
Throttle
servo horn
89126
Throttle
link
25201
3x8mm
fhcs
89126
Throttle
spring
25225
3x3mm
setscrew
25225
3x3mm
setscrew
89126
Set collar
89218
3x8mm
washer
89126
Brake bias
block
89008
Servo cone
washer
25215
M3
locknut
89126
Brake
bias
collar
89318
Brake
lever
89216
Throttle
pivot
89202
3x12mm
bhcs
89008
Servo
horn ring 89203
3x16mm
bhcs
89126
Throttle
ball cup
25225
3x3mm
setscrew
89126
Brake
bias
collar
x2
x2
x2
x2
x2
x2
#1596
thread lock
!
#1596
thread lock
#1596
thread lock
