Team Associated RC8.2 User Manual
Page 31
31
:: Air Filter Install - Bag L
:: Engine Install - Bag L
:: Engine Install (cont.) - Bag L
25201
3x8mm
fhcs
89133
1.0mm
clutch
springs
89231
3mm
lock
washer
89135
Clutch nut
89223
3x8mm
shcs
89218
3x8mm
washer
89132
16T
clutchbell
89138
Flywheel
collet
89134
Clutch shoes
(aluminum)
89139
Air filter
cap
89140
Air filter
hose
3719
6” wire tie
89139
Air filter
base
89137
Clutch
shim
89148
Clutchbell
shim
89224
3x16mm
shcs
89257
Engine
mount
25237
5x10mm
bearing
89136
Flywheel
89141
Air filter
inner
element
89142
Air filter
outer
element
x2
x3
x4
x5
x4
x2
x2
x3
When oiling
the filter
elements,
place both
inside a
plastic bag
and squeeze
to help
evenly coat
the filter.
Use #3917
wire tie
here!
Engine not
included!
Use upper shock
tool to install
clutch springs.
Muffler and header
not included
!
!
!
!
!
!
filter
oil #7710
filter
oil #7710
RACERS TIP:
trim clutch shim.
Clutch shimming
instructions:
If assembly does
not spin freely,
use #89218
(small clutch shim
included in kit) on
screw to increase
end play.
If crankcase
extends past
clutch bearing,
use#89218
(large clutch shim
included in kit) to
reduce end play.
#1596
thread lock
