1.3 Before You Start
There are certain general operating principles and terms that should be understood before continuing to use this manual.
Please read this chapter carefully before proceeding.
1.3.1 Worksurface Layout ..............................................................
Left & Right Sections
Quick Select Switches
Rotary Resolution
Screen Scroll
2nd Function & Option/All
Assignable Rotaries and Switches
Aux / Pan / Dynamics/FX Controls
Mute and Interactive LCD
Function Button
Channels Faders
ALT Input Switch Meter View Switch
Channel Inserts A & B On/Off
Direct Out On/Off
4 Band Dynamic Parametric EQ
High and Low Pass Filters
Multiband Dynamics
Thresholds & On / Off
Joystick
Hard Mute & Full Safe
Channel Scroll & Undo/Redo
Layer Switch
Channel Fader Banks
Centre Section
Rotary Resolution
Channel Faders/Mutes &
LCD Function Buttons
Phones Solo 1 & 2 Controls Screen Scroll
Dynamic Automation
Snapshot Controls
Macros
Monitoring Matrix
Channel Fader Banks &
Assignable Master Fader
Touch/Turn
Talkback
Screen Switch
