STRAIGHT RAIL INSTALLATION GUIDELINES for
AZEK Premier AZEK Trademark AZEK Reserve
Page 4
© 2013 AZEK Building Products. All rights reserved
14 Tighten Bottom
Bracket Flange
Rail assembly
from step
10
11 Hook Rail Section
Onto Bottom
Bracket Flange
X 3
Tip If using Swing Brackets, swing End
Balusters back to plumb and attach to top retainer
Attach Handrail to Top
Retainer 15
X 4
Tip
If using Swing
Brackets,
swing End
Balusters
away from
posts for
better
clearance
13 Attach Rail Section
to Posts
Do not over
torque screws
when fastening
bracket to
posts as this
may cause post
sleeves to crack
IMPORTANT:
Rail assembly from step 7 10 Slide Handrail
onto Rail
Section
IMPORTANT
Make sure that
the DRIVE
TOOL/DRILL is
configured or set
to use the
SCREW setting
when driving
and/or
tightening all
FASTENERS.
IMPORTANT
Make sure that
the DRIVE
TOOL/DRILL is
configured or set
to use the
SCREW setting
when driving
and/or
tightening all
FASTENERS.
IMPORTANT:
• Drill holes for
brackets at the
same angle that
screws will be
installed
• Be sure to only
drill through
Post Sleeve
With
Drill Bit
Now
Drill
3 / 16 ”
Remove rail assembly and
drill for Top Retainer Brackets
Rail assembly
from step
10
Mark for Top
Retainer Brackets 12
Note: Composite Baluster shown.
Note: Swing bracket not used with metal baluster.
