Zoom SHOT WallVIEW SR
ZoomSHOT WallVIEW SR System Document Number 342-0651 Rev B
Page 12 of 16
A
PPENDIX
1:
P
IN
-
OUTS FOR
Z
OOM
SHOT
C
AMERA
Table EZCamera
Power & HD Video RJ-45 Connector Pin-outs
ZoomSHOT EZPOWER HD VIDEO PORT
Important Note:
The EZ POWER HD VIDEO RJ-45 Connector is for use with the Quick-Connect SR,
Quick-Connect DVI/HDMI SR, Quick-Connect USB and USB Mini
Interfaces ONLY (568B Wiring
Standard). The video signals are differential (HSDS™) and can only be received by the interfaces
above.
ZoomSHOT Camera RS-232 Port
Pin #
Function
Pin - 1
N/A
Pin - 2
N/A
Pin - 3
N/A
Pin - 4
IR Output (Diff Signal to Quick-Connect)
Pin - 5
IR Ground (Diff Signal to Quick-Connect)
Pin - 6
Digital GND
Pin - 7
RXD (from TXD of control source)
Pin - 8
TXD (to RXD of control source)
A
PPENDIX
2:
P
IN
-
OUTS FOR
Q
UICK
-C
ONNECT
SR
I
NTERFACE
Table: DE-15 - YPbPr Pin-Out
Pin
YPbPr
1
Power+
2
Power-
3
Y+
4
PB+
5
PB -
6
Y -
7
PR+
8
PR-
Pin
YPbPr
1
Pr
2
Y
3
Pb
4
-
5
-
6
Pr GND
7
Y GND
8
Pb GND
9
-
10
GND
11
-
12
-
13
-
14
-
15
-
12345678
EZ POWER
HD VIDEO
RS-232
12345678
