G
ENERAL
S
PECIFICATIONS
WideSHOT WallVIEW USB
Part Numbers
WideSHOT WallVIEW Mini System 999-6911-100 (North America)
WideSHOT WallVIEW Mini System 999-6911-101 (International)
WideSHOT Camera
Image Sensor
1/3-Type Progressive Scan CMOS Sensor with 1.3 Megapixels (720p native)
Video Output Resolutions
HD: 1080/59.94/50/30/25, 1080i/59.94/50, 720p/59.94/50
SD: 480p/59.94 & 576p/50
Lens/ Focal Length
Approx. 3X Optical Zoom, 3.3mm to 10.5mm manual focus
Horizontal Viewing Angle
82.2° Wide End to 3.2° Tele End, 27.4° Tele End, 16:9 Format (94.3° diagonal)
Video S/N Ratio
>50 dB
Minimum Illumination
0.2 LUX (1/30 Shutter Speed) Color
Serial Control Protocol
RS-232 Serial Control
Manual Pan/Tilt Range
Pan: Limited to service loop of cabling, yoke and base are mechanical only
Tilt: ± 30°
Invertible for Ceiling Mount
Preset Positions
Manual pan, tilt zoom only
Tally Light
Red LED available through RS-232 Control
Camera Connectors
Two (2) RJ-45 Jacks:
EZ-Power VIDEO RJ-45 Jack for use with Quick-Connect - Supplies power to the camera and returns
differential HD video from the camera
RS-232 RJ-45 Jack (RS-232 Communication and IR Out (with Quick-Connect -SR Interfaces)
HD Video Select
16-Position Rotary Switch: Used to set HD Video Resolution Output
Camera Settings
6-Position Dip Switch: For IR Freq., Image Flip & Test Bars
16-Position Rotary Switch for Output Resolution Settings
Thin Profile Wall Mount
535-2000-237 (Provided with WideSHOT WallVIEW Systems)
Black powder coating, Sized to fit on 1-gang wall box or with supplied drywall fasteners
User Controls
IR SHOT Commander with OSD for set-up and RS-232
Materials & Weight
Aluminum & Steel, Weight = 2.75643 lbs. (1.68kg)
Dimensions:
Tube: 3.5” ( 88.9mm) Diameter x 5.125” (130.175mm) Long (including front bezel and focus knob)
Base: 5.5” (139.7mm) Diameter
Overall Height: 5.5” (139.7mm) Tall
USB Mini Interface
Video Outputs
USB 2.0 (MJPEG): Resolution up to 720p/30 (Limits of USB 2.0 with MJPEG Compression)
USB Interface
Connector: Type-B, USB 2.0 Compliant, Standard UVC (Universal Video Class) Drivers
Network Interface
Ethernet over USB 2.0 only
Streaming Protocols
USB 2.0, MJPEG (UVC standard drivers)
Connectors
Power: 5.5mm OD x 2.5mm ID Coaxial Connector
RS-232 Port: Shielded RJ-45 Jack
EZ-Power Video Port: Shielded RJ-45 Jack (Power and Differential HD Video)
Supported Media Players
Quick-Time Media Play - Win 7 & Mac OS10X
VLC Media Player - Win 7 & Mac OS10X
Real Player - Win 7
Supported Browsers
Internet Explorer
Safari
Safari/iOS
Chrome
Fire Fox
Power Supply
24 VDC, 2.08 Amp
Dimensions (H x W x D)
3.60” (91.4mm) H x 4.48” (113.8mm) W x 1.25” (31.75mm) D
Weight
1.1 lbs. (0.5Kg)
Accessories
6’ (1.83m) USB 2.0 Type-A Male to USB Type-B Male cable (included),
24 VDC, 2.08 Amp Switching Power Supply with AC Cord Set (included)
Two (2) Cat-5 cables (not included - unknown length requirement)
Operating Temperatures
0°C to 40°C / 20% to 80% Relative Humidity
Power Consumption
Maximum: <25 watts
