UXHD CrossPoint Installation and User Guide 341-929 Rev. A Page 5 of 12
An Important Note about Video vs. RGBHV:
Even in the analog realm, YPbPr video is quite a bit different than analog RGBHV and they were created or evolved for
different purposes. RGBHV monitors have to work with all the computers on the market and the vast majority of RGBHV
monitors have picture sizing and positioning controls. On the other hand, TVs, or pure HD video monitors do not have
these same controls, and since every TV has to catch and present several modes of broadcast (cable, satellite, on-air)
TV, these monitors will overscan all images so the sync or blanking pulses (the data part of the video frame, but not the
picture) are not seen on the TV. So, when you are converting a PC’s RGBHV to HD video and part of the start bar and
some icons get partially cut off…this is very, very normal. The display, at least the more modern models, should be
equipped with a “Full Pixel” mode of some kind that will display all the PC’s pixels and not cut off any part of the start bar
and icons, but there may be a bit of underscan to appreciate depending on manufacturer.
Technical Specifications
UXHD CrossPoint
Part Numbers: 999-5690-000 (North America), 999-5690-001 (International)
Video Formats Supported:
3Gb/s HD- SDI/SDI Components Support SMPTE 424M, SMPTE 292M, SMPTE 259M-C, YPbPr up to
1080p/60, RGBHV (see tables below), Y/C & CVBS (NTSC & PAL)
Analog/Digital Video Inputs: One (1) RGBHV, HD (YPbPr) or SD (Y/C or CVBS) / One (1) HD-SDI/SDI on BNC
Analog/Digital Video Output: One (1) RGBHV, HD (YPbPr) or SD (Y/C or CVBS) / One (1) HD-SDI/SDI on BNC
Control Port: One (1) RS-232 on DB-9
LCD Display: 2-line Blue Backlit LCD Display
Power Requirements: PowerRite 12 VDC, 3.0 Amp
Reference Input: BNC-Female
BNC Connector Type: Circuit Board Edge Mount (3Gb/s compliant) Carrier Class BNCs with Gold Finish Body and Contacts
Weight: 3.2 lbs. (1.45329107kg) – approximate weight
Dimensions (H x W x D): 1.72” (4.4cm) H x 19” (48.3cm) W x 6” (15.2cm) D
Accessory Option Standard Definition (Y/C & CVBS) Adapter Cable 440-5600-000 (DE-15M to 3-BNC-F)
UXHD CrossPoint Resolution Tables
INPUT 1 - Signal Formats Supported Resolutions Aspect Ratio
YPbPr 720p 59.94/50
1080i 59.94/50
1080p 60/50 ALL 16:9
RGBHV 640 x 480 @ 60Hz - VGA
800 x 600 @ 60Hz - SVGA
1024 x 768 @ 60Hz - XGA
1280 x 768 @ 60Hz - WXGA
1280 x 800 @ 60HZ - WXGA
1280 x 1024 @ 60Hz - SXGA
1360 x 768 @ 60 Hz - WXGA
1366 x 768 @ 60Hz - WXGA
1400 x 1050 @ 60Hz - SXGA+
1600 x 1200 @ 60Hz - UXGA
4:3
4:3
4:3
15:9
16:10 (8:5)
5:4
16:9
16:9
4:3
4:3
Std Definition - w/Adapter Cable 480i 29.97, 576i 25 4:3
INPUT 2 - Signal Formats Supported Resolutions Aspect Ratio
SDI 480i 29.97, 576i 25 4:3
HD-SDI 720p 59.94/50
1080i 59.94/50
1080p 60/50/30/25 16:9
OUTPUT 1 - Signal Formats Supported Resolutions Aspect Ratio
YPbPr 720p 50/59.94,
1080i 50/59.94
1080p 50/60 ALL 16:9
RGBHV 640 x 480 @ 60Hz - VGA
800 x 600 @ 60Hz - SVGA
1024 x 768 @ 60Hz - XGA
1280 x 768 @ 60Hz - WXGA
1280 x 800 @ 60HZ - WXGA
1280 x 1024 @ 60Hz - SXGA
1360 x 768 @ 60 Hz - WXGA
1366 x 768 @ 60Hz - WXGA
1400 x 1050 @ 60Hz - SXGA+
1600 x 1200 @ 60Hz - UXGA
1920 x 1200 @60 HZ - WUXGA* *With reduced blanking
4:3
4:3
4:3
15:9
16:10 (8:5)
5:4
16:9
16:9
4:3
4:3
16:10
Std Definition - w/Adapter Cable 480i 29.97, 576i 25 4:3
OUTPUT 2 - Signal Formats Supported Resolutions Aspect Ratio
SDI 480i 29.97, 576i 25 4:3
HD-SDI 720p 59.94/50
1080i 59.94/50
1080p 60/50/30/25 16:9
