Control and
Response to control
Response to Confirmation PH300 PH300A PH500 PH600 PH350
PH400
w/RP400
or w/IF400
PH360 PH650 PH405 HE100
ITEM Responce
Command
Data Contents
Data
Remarks
Control
Command
Reply for
Confirmation
Command
Limitation Setting #L[Data] --- l[Data]
Controller -> P/T
1
2
3
4
P/T -> Cnotroller
0
1
Tilt Up
Tilt Down
Pan Left
Pan Right
Release
Set
V1.00L01
Landing Setting #N[Data] --- --- 0
1 Just Landing
Soft Landing --- V1.00L01
Request Zoom
Position
(Output D/A Data)
--- #GZ gz[Data]
555h
-
FFFh
"---"
Wide
-
Tele
@Power OFF
--- V1.00L01
Request Focus
Position
(Output D/A Data)
--- #GF gf[Data]
555h
-
FFFh
"---"
Near
-
Far
@Power OFF
--- V1.00L01
Request Iris Position
(Output D/A Data) --- #GI gi[Data1][data2]
[data1]
555h
-
FFFh
"---"
[data2]
0
1
[data1]
Close
-
Open
@Power OFF
[data2]
Manual Iris
Auto Iris
@Iris Manual --- V1.00L01
Tilt Range #AGL[Data] --- aGL[Data]
0
1 --- --- --- --- --- --- --- --- V1.00L01
@TILT
RANGE SW
is ON
Request Software
Vertion --- #V? [Version Data] --- V1.00L01
Narrow(190deg)
Wide(300deg)
P/T Command([Command][CR]) 26/26
