Vaddio Panasonic AW-HE-100 Protocol - Manual (Page 24)

Control and
Response to control
Response to Confirmation PH300 PH300A PH500 PH600 PH350
PH400
w/RP400
or w/IF400
PH360 PH650 PH405 HE100
Power #O[Data] p[Data]
0
f
1
n
2
Power OFF
Power OFF
Power ON
Power ON
---
Power OFF
Power OFF
Power ON(w/ Camera TX)
Power ON(wo/ Camera TX)
Camera Power & P/T
Control
Pan Speed Control #P[Data] --- ---
01
-
50
-
99
Max. Speed
-
Stop
-
Max. Speed
V1.00L01
Tilt Speed Control #T[Data] --- ---
01
-
50
-
99
Max. Speed
-
Stop
-
Max. Speed
V1.00L01
Pan/Tilt Position
Control #U[Data1]
[Data2][Data3] --- u[Data1][Data2]
[Data1]
0000h
-
FFFFh
[Data2]
0000h
-
FFFFh
[Data3]
01h
-
FFh
[Data1]
Pan Position
Center=8000h
[Data2]
Tilt Position
Center=8000h
[Data3]
Checksum
[Data1]
Pan Position
Center=8000h
[Data2]
Tilt Position
Center=8000h
--- --- V1.00L01
Zoom Speed Control #Z[Data] --- ---
01
-
49
50
51
-
99
Wide Max. Speed
-
Wide Min. Speed
Stop
Tele Min. Speed
-
Tele Max. Speed
V1.00L01
Zoom Position
Control #AXZ[Data] --- axz[Data]
555h
-
FFFh
--- --- V1.00L01
Zoom Position
Control
#AYZ[Data] --- axz[Data]
[Response to control]
001
-
999
[Response to Confirmation]
555h
-
FFFh
Wide
-
Tele
Wide
-
Tele
--- --- V1.00L01
Focus Speed Control #F[Data] --- ---
01
-
49
50
51
-
99
Near Max. Speed
-
Near Min. Speed
Stop
Far Min. Speed
-
Far Max. Speed
V1.00L01
Focus Position
Control #AXF[Data] --- axf[Data]
555h
-
FFFh
--- --- V1.00L01
Focus Position
Control #AYF[Data] --- axf[Data]
[Response to control]
001
-
999
[Response to Confirmation]
555h
-
FFFh
Near
-
Far
Near
-
Far
--- --- V1.00L01
Roll Speed Control #RO[Data] --- ---
01
-
49
50
51
-
99
CCW Max. Speed
-
CCW Min. Speed
Stop
CW Min. Speed
-
CW Max. Speed
--- --- --- --- --- with RL400 --- --- --- ---
Iris Control #I[Data] --- ---
01
-
99
Iris Close
-
Iris Open
V1.00L01
Iris Control #AXI[Data] --- axi[Data]
555h
-
FFFh
V1.00L01 Iris Close
-
Iris Open
Wide
-
Tele
Near
-
Far
ITEM Responce
Command
with Camera TX -> Controller RX line without Camera TX -> Controller RX line
Data Contents
Data
Remarks
Control
Command
Reply for
Confirmation
Command
P/T Command([Command][CR]) 24/26
