D0 Mode
45
Translating Parameters
Zoom position
There is no change for EVI-D80N/D80P. EVI-D90N/
D90P employ an 18× optical zoom lens but there are
no translating parameters. The zoom ratio and
corresponding position data are as shown in the table
below (for reference).
Zoom Ratio
× 18 Lens
Optical Zoom
Position Data
Ч 1
0000
Ч 2
1606
Ч 3
2151
Ч 4
2860
Ч 5
2CB5
Ч 6
3060
Ч 7
32D3
Ч 8
3545
Ч 9
3727
Ч 10
38A9
× 11
3A42
× 12
3B4B
× 13
3C85
× 14
3D75
× 15
3E4E
× 16
3EF7
× 17
3FA0
× 18
4000
Pan/tilt speed
The actual speed that is defined by the parameters
corresponds to that of the D70.
When the camera receives commands such as
PantiltDrive Home, Reset, or CAM_Memory Recall,
that do not include speed indications, these operations
are carried out at the same speed as they would be
when the D70 mode is set to OFF.
Speed (deg/sec)
Parameters
D80N/
D80P
D90N/
D90P
D70
01h
1.7
1.3
1.7
02h
2.2
1.7
2.2
03h
2.9
2.2
2.9
04h
4.1
3.2
4.1
05h
6.8
5.4
6.8
06h
11
11
11
07h
16
16
16
08h
21
21
21
09h
27
27
27
0Ah
31
31
31
0Bh
35
35
35
0Ch
40
40
40
0Dh
42
42
47
0Eh
44
44
49
0Fh
46
46
54
10h
48
48
56
11h
50
50
62
12h
79
79
64
13h
81
81
69
14h
83
83
72
15h
85
85
79
16h
87
87
84
17h
90
90
90
18h
1)
100
100
100
1) Max. pan speed is 18h; max. tilt speed is 17h.
