Command List
EVI-D80N/D80P/D90N/D90P Command List (3/3)
Command Set Command Command Packet Comments
CAM_PictureEffect Off 8x 01 04 63 00 FF Picture Effect Setting
Neg.Art 8x 01 04 63 02 FF
B&W 8x 01 04 63 04 FF
CAM_ICR 5) On 8x 01 04 01 02 FF Infrared Mode ON/OFF
Off 8x 01 04 01 03 FF
CAM_AutoICR 5) On 8x 01 04 51 02 FF Auto dark-field mode On/Off
Off 8x 01 04 51 03 FF
Threshold 8x 01 04 21 00 00 0p 0q FF pq: ICR ON → OFF Threshold Level
CAM_Memory Reset 3) 6) 8x 01 04 3F 00 0p FF p: Memory Number (=0 to 5)
Corresponds to 1 to 6 on the Remote Commander.
Set 3) 6) 8x 01 04 3F 01 0p FF
Recall 3) 4) 8x 01 04 3F 02 0p FF
CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000 to FFFF)
SYS_Menu Off 8x 01 06 06 03 FF Turns off the menu screen.
IR_Receive On 8x 01 06 08 02 FF IR(remote commander) receive ON/OFF
Off 8x 01 06 08 03 FF
On/Off 8x 01 06 08 10 FF
IR_ReceiveReturn On 8x 01 7D 01 03 00 00 FF IR (remote commander) receive message via the VISCA
communication ON/OFF
Off 8x 01 7D 01 13 00 00 FF For contents of messages, see page 33.
Information Display On 8x 01 7E 01 18 02 FF ON/OFF of the Operation status display of One Push
Off 8x 01 7E 01 18 03 FF Trigger of CAM_Memory and CAM_WB
Pan-tiltDrive Up 3) 8x 01 06 01 VV WW 03 01 FF VV: Pan speed 01 to 18
WW: Tilt Speed 01 to 17
YYYY: Pan Position E1E5 to 1E1B (center 0000)
ZZZZ: Tilt Position FC75 to 0FF0 (IMAGE FLIP: OFF)
(center 0000)
Tilt Position F010 to 038B (IMAGE FLIP: ON)
(center 0000)
See page 42
Down 3) 8x 01 06 01 VV WW 03 02 FF
Left 3) 8x 01 06 01 VV WW 01 03 FF
Right 3) 8x 01 06 01 VV WW 02 03 FF
UpLeft 3) 8x 01 06 01 VV WW 01 01 FF
UpRight 3) 8x 01 06 01 VV WW 02 01 FF
DownLeft 3) 8x 01 06 01 VV WW 01 02 FF
DownRight 3) 8x 01 06 01 VV WW 02 02 FF
Stop 3) 8x 01 06 01 VV WW 03 03 FF
AbsolutePosition 8x 01 06 02 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
RelativePosition 8x 01 06 03 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
Home 8x 01 06 04 FF
Reset 8x 01 06 05 FF
Pan-tiltLimitSet LimitSet 8x 01 06 07 00 0W
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF W: 1 UpRight
YYYY: Pan Limit Position 0001 to 1E1B
ZZZZ: Tilt Limit Position 0001 to 0FF0 (IMAGE FLIP: OFF)
Tilt Limit Position 0001 to 038B (IMAGE FLIP: ON)
W: 0 DownLeft
YYYY: Pan Limit Position E1E5 to FFFF
ZZZZ: Tilt Limit Position FC75 to FFFF (IMAGE FLIP: OFF)
Tilt Limit Position F010 to FFFF (IMAGE FLIP: ON)
LimitClear 8x 01 06 07 01 0W
07 0F 0F 0F 07 0F 0F 0F FF
1) After an ACK to a One Push White Balance Trigger is sent until the operation is completed, “Not Executable” is sent as a reply when any
other commands are received.
2) Bright can be set only in Full Auto mode or Shutter Priority mode.
3) When the menu is displayed, this operation is ignored.
4) When other commands are received after a Completion notification for the Recall command is sent, “Command not executable” may be
returned for a maximum of 240 msec due to internal processing. In this case, please transmit the command again.
5) The command is available on EVI-D90N/P only.
6) If Information Display is set to ON, the next command action may be delayed due to Operation status display internal processing after
these commands are executed.
