CeilingVIEW HD-18 DocCAM Series
CeilingVIEW HD-18 DocCAM Manual - Document Number 342-0195 Rev. B 4 of 24
Packages:
Depending on the package ordered, the contents of the systems differ. There are two (2) Quick-Connect options;
Quick-Connect SR Interface and Quick-Connect DVI/HDMI SR Interface, two (2) geographic options (North
America and International) and finally an option for the Quick-Connect CCU Controller that works with any system
aforementioned above. The CeilingVIEW HD-18 DocCAM product line is flexible with many options. The
following information will cover all the combinations available:
Unpacking:
Carefully remove the CeilingVIEW HD-18 DocCAM camera assembly and all of the hardware from the packaging.
CeilingVIEW HD-18 DocCAM - 999-3018-000 (North America)
x One (1) Complete CeilingVIEW HD-18 DocCAM Module and Back Box
x One (1) White Trim Ring
x Two (2) White,10-32 x !” Phillips Flat Head Screws for Trim Ring
x One (1) Quick-Connect SR Interface (998-1105-016)
x One (1) Vaddio CeilingVIEW HD-18 DocCAM IR Remote Control
x One (1) RJ-45 to RS-232 Control Adapter (998-1001-232)
x One (1) Tile Support Brace (one piece)
x One (1) 24 VDC PowerRite™ Power Supply
x One (1) AC Power Cord for North America
x Documentation
CeilingVIEW HD-18 DocCAM - 999-3018-001 (International)
x One (1) Complete CeilingVIEW HD-18 DocCAM Module and Back Box
x One (1) White Trim Ring
x Two (2) White,10-32 x !” Phillips Flat Head Screws for Trim Ring
x One (1) Quick-Connect SR Interface (998-1105-016)
x One (1) Vaddio CeilingVIEW HD-18 DocCAM IR Remote Control
x One (1) RJ-45 to RS-232 Control Adapter (998-1001-232)
x One (1) Tile Support Brace (one piece)
x One (1) 24 VDC PowerRite™ Power Supply
x One (1) Euro Power Cord
x One (1) UK Power Cord
x Documentation
CeilingVIEW HD-18 DocCAM DVI/HDMI - 999-3028-000 (North America)
x One (1) Complete CeilingVIEW HD-18 DocCAM Module and Back Box
x One (1) White Trim Ring
x Two (2) White,10-32 x !” Phillips Flat Head Screws for Trim Ring
x One (1) Quick-Connect DVI/HDMI SR Interface (998-1105-018)
x One (1) Vaddio CeilingVIEW HD-18 DocCAM IR Remote Control
x One (1) RJ-45 to RS-232 Control Adapter (998-1001-232)
x One (1) Tile Support Brace (one piece)
x One (1) 24 VDC PowerRite™ Power Supply
x One (1) AC Power Cord for North America
x Documentation
CeilingVIEW HD-18 DocCAM DVI/HDMI - 999-3028-001 (International)
x One (1) Complete CeilingVIEW HD-18 DocCAM Module and Back Box
x One (1) White Trim Ring
x Two (2) White,10-32 x !” Phillips Flat Head Screws for Trim Ring
x One (1) Quick-Connect DVI/HDMI SR Interface (998-1105-018)
x One (1) Vaddio CeilingVIEW HD-18 DocCAM IR Remote Control
x One (1) RJ-45 to RS-232 Control Adapter (998-1001-232)
x One (1) Tile Support Brace (one piece)
x One (1) 24 VDC PowerRite™ Power Supply
x One (1) Euro Power Cord
x One (1) UK Power Cord
x Documentation
CeilingVIEW HD-18 DocCAM Mounted in
a Ceiling Tile (above) & Quick-Connect
SR Interface (below)
CeilingVIEW HD-18 DocCAM Mounted in
a Ceiling Tile (above) & Quick-Connect
DVI/HDMI SR Interface (below)
