AV Bridge CONFERENCE
Vaddio AV Bridge CONFERENCE - Document Number 342-0767 Rev A Page 21 of 32
General Specifications
Part Numbers
AV Bridge CONFERENCE 999-8215-000 - North America
AV Bridge CONFERENCE 999-8215-001 - International
Firmware Release 1.0.0
Video Encoding: H.264 (IP) or MJPEG (USB)
Resolution up to 1080/30 (IP) or 720P/30 (USB)
Audio Encoding: AAC (IP) or PCM (USB)
Variable Bit Rates for IP
Supported Media Players
Real Media Player, QuickTime, VLC Media Player
Video Inputs & Supported Video
Resolutions:
Connectors: HDMI, DE-15 (for YPbPr and RGBHV) and BNC-F for Std. Def.
HDMI and YPbPr:
1080p/60/59.94/50/30/25 frames/s, 720p/60/59.94/50 frames/s,
1080i/59.94/50 fields/sec, 1080p/24 (on HDMI input only)
RGBHV (VESA RESOLUTIONS):
1280 x 720@60Hz (16:9), 1280x768@60Hz (15:9)m, 1280x800@60Hz (16:10),
1360 x 768@60Hz (16:9), 1024 x 768@60Hz (4:3 centered in 16:9 frame)
DVI (on HDMI connector using sRGB color space):
1080p/60/59.94/50/frames/s, 720p/60/59.94/50Hz frames/s
1080i/59.94/50Hz, fields/sec, 1440 x 900@60Hz, 1360 x 768@60Hz,
1280 x 800@60 Hz, 1280 x 768@60Hz, 1280 x 720@60Hz,
EDID Supported Resolutions:
1080p/60/59.94/50/frames/s, 720p/60/59.94/50Hz frames/s, 1440 x 900@60Hz,
1360x768 @ 60Hz, 1280x800 @ 60 Hz
Composite (SD-Standard Definition):
480i/29.97Hz NTSC, 576i/25Hz PAL
Video Processing
Auto Scaling, Noise Filter, Deinterlacing
Analog Audio Input
XLR-F(balanced 10k ohm) Nominal Line Level +4dBu
RCA-F (unbalanced 10k ohm) Nominal Line Level -10dBV
Analog Audio Output
XLR-M (balanced 50 ohm)
RCA-F (unbalanced 10k ohm)
Audio Processing
AGC, High Pass and Low Pass Filters
USB 2.0 Interface
Connector Type-B Female, USB 2.0 Compliant
Supported Drivers: USB Video Class, (UVC), USB Audio Class (UAC)
No Custom Drivers, Custom Programs or Headaches Required
Network Interface
Connector: RJ-45
Type 10/100 Base-T
IP Streaming Supported
RTSP or HLS (Apple’s HTTP Live Streaming)
RS-232 Port
Connector: RJ-45
User Controls and Configuration
Front panel LCD and controls for high use functions such as video input
select, volume, streaming type and for viewing network information
Embedded web server for advanced configurations and administration
Rear panel dip switches (restore factory defaults and future functions)
Power Supply
Connector: 5.5mm OD x 2.5mm ID Coaxial
18VDC, 2.75 Amp
Operating Temperature
32° to 104° F (0° to 40° C)
Power Consumption
Less than 50 Watts
Dimensions (WxHxD)
18.93” W x 1.72” H x 7.0” D
Weight
3.14159321 lbs. (1.425 kg)
