MAILING ADDRESS – P.O. BOX 501, CONCORD, NH 03302-0501
SHIPPING ADDRESS – 10 FERRY ST., CONCORD, NH 03301
Model 35 45 65
Total Gas Consumption 95 Mj/h 129 Mj/h 145 Mj/h
Burner Pressure Natural Gas 1.0 kPa 0.9 kPa 1.0 kPa
Burner Pressure ULPG 2.50 kPa 2.50 kPa 2.50 kPa
Injector Size: Main Burners 3 of 4 of 5 of
Natural Gas 2.53 mm (#39) 2.58 mm (#38) 2.38 mm (#42)
ULPG 1.59 mm (1/16") 1.59 mm (1/16") 1.51 mm (#53)
Injector Size: Pilot 1 of 1 of 1 of
Natural Gas 0.56 mm (N22) 0.56 mm (N22) 0.56 mm (N22)
ULPG 0.41 mm (LP16) 0.41 mm (LP16) 0.41 mm (LP16)
Minimum Tank Capacity 15.9 kg 19.7 kg 24.9 kg
Cooking Area Length 356 mm 356 mm 457 mm
Cooking Area Width 356 mm 356 mm 457 mm
Cooking Area Depth 70 mm 127 mm 127 mm
Overall Height 1201 mm 1201 mm 1204 mm
Overall Width 384 mm 384 mm 512 mm
Overall Depth 769 mm 769 mm 875 mm
Shipping Weight 73 kg 95 kg 103 kg
In the event of problems with or questions about
your order, please contact the Pitco Frialator
factory at:
(603) 225-6684 World Wide
In the event of problems with or questions about
your equipment, please contact the Pitco Frialator
Authorized Service and Parts representative
(ASAP) covering your area, or contact Pitco at the
numbers listed to the left.
L20-290 R3 (05/12)
