08/13 Rev. C 146527 6
SPECIFICATIONS
Product Solid Door Freezer Solid Door Refrigerator
MODEL F23-S F49-S F72-S R23-S R49-S R72-S
Capacity (CuFt) 23 49 72 23 49 72
Exterior
Dimensions
(including casters)
(W) 27.4” 55.2” 78.0” 27.4” 55.2” 78.0”
(D) 31.3” 31.3”
(H) 83.7” 83.7”
Swing Doors 1 2 3 1 2 3
Shelves 4 8 12 4 8 12
Compressor 1/2HP 3/4HP 1.1HP 3/8HP 3/8HP 1/2HP
Power Voltage 115V 115V
115/208-
230V
115V
Plug In-Installation NEMA 5-15P
NEMA
14-20P
NEMA 5-15P
Amps 8.5 9.5 9.0 7.5 7.5 10.0
Range of Temperature Below 0 °F +32°F ~ +40°F
Refrigerant R-404a R-134a
Net Weight (lbs) 295 499 622 288 475 609
 Above specifications are subjected to change without prior notice for quality
improvement.
 The nameplate (includes Serial Number) is located on the upper left of the cabinet
interior.
