2. ELECTRONIC CONTROLLER DISPLAY LEGEND
Display Description
St Temperature Setting Mode
di Temperature Differential Setting Mode
th Cabinet Temperature Verification Mode
dt Defrost Frequency Setting Mode
tb Rapid Freeze Mode
dF Forced Defrost Mode
ELECTRONIC CONTROL SETTINGS
Setting Temperature-
The temperature set point is adjustable from -22
˚F to +8˚F for the freezers and +25˚F to
+50
˚F for refrigerators. The default set point is -5˚F for freezers and +36˚F for
refrigerators.
To set or adjust the cabinet temperature;
• Press the ‘Mode/Set’ button.
• Press the ‘Up’ or ‘Down’ button until is displayed.
• Press the ‘Mode/Set’ button to display current temperature set point.
• Press ‘Up’ or ‘Down’ buttons until desired set point is displayed.
• Press ‘Mode/Set’ button to set the new value.
• Press “Up’ or “Down’ button until is displayed.
• Press ‘Verify’ button to return to display cabinet temperature.
Setting Temperature Differential-
The temperature differential is the amount of swing that the cabinet temperature does
either side of the temperature set point. If the temperature set point is +36
˚F and the
temperature differential is +8
˚F, the compressor will start when the control shows +40˚F
and stop when the control shows +32
˚F. The default temperature differential set point is
+8
˚F and the range is +4˚F to +16˚F.
To set the temperature differential;
• Press ‘Mode/Set’ button.
• Press ‘Up’ or ‘Down’ button until is displayed.
• Press ‘Mode/Set’ button to see current temperature differential setting.
• Press ‘Up’ or ‘Down’ button until the desired value is displayed.
• Press ‘Mode/Set’ button to set the value.
• Press ‘Up’ or ‘Down’ button until is displayed.
• Press ‘Verify’ button to return to display cabinet temperature.
Rapid Freeze Mode (freezers only)-
When in rapid freeze mode the compressor will run continuously for 120 minutes and
then return to normal operation and set points.
