E6 SERVICE MANUAL REV C 06/12
48
Error
Code
Oven Series
Error/Event
Condition
Description Trigger
Error
Level
System
Response
E102
E2, E3, E4, E5 Heater On
Convection
Heater element
failed to turn OFF
when requested The current
measured by the
SRB is >1 amp
with the convection
heater OFF
Critical
"E102 HEATER
ON WITHOUT
REQUEST"
message is
written to the
error log.
E6 High Heater On
High Convection
Heater element
failed to turn OFF
when requested The current
measured by the
SRB is >1 amp
with the high
heater OFF
Critical
"E102 HIGH
HEATER ON
WITHOUT
REQUEST"
message is
written to the
E103 All Ambient overheat
The temperature
measured inside
the ovens cabinet
is too high The ambient
temperature
measured by the
QTS and or SRB
is >70°C (158°F)
Warning
"E103 AMBIENT
OVERHEAT.
PLEASE
REMOVE,
CLEAN AND
REPLACE THE
E104
All
Overheat stats
released
The cavity
temperature is
above the high
limit Cavity thermal
switch's (TCO)
have opened
Critical
"E104
OVERHEAT
STATS
RELEASED"
message is
written to the
The magnetron(s)
temperature is
above the high
limit and the
magnetron(s) are
off Magnetron thermal
switch's (TCO)
have opened and
the Magnetron(s)
are off
E105 All High or low freq
The frequency is
outside of the
ovens range of
operation The SRB's line
monitoring circuit
detects that that
the frequency is
outside of the ±
2Hz range
Critical
"E105 SUPPLY
FREQUENCY
(Hz) OUT OF
RANGE"
message is
written to the
E106 All Cavity overheat
Cavity
temperature is
higher than the
set point range
while cooking The SRB has
detected that the
cavity temperature
is greater than
25°C (77°F) above
the setpoint the
Critical
"E106CAVITY
OVERHEATED"
message is
displayed in the
error log.
"E106CAVITY
E107
All Comm error
There is no
communication
between the QTS
and the SRB The QTS can no
longer send or
receive data from
the SRB.
Critical
“E107 COMM
ERROR"
message is
displayed on the
screen.
If h bl i
The SRB no longer
receives data from
the QTS.
SRB writes error
to the log.
