Specifications
INTERCHANGEABLE LENS FOR DIGITAL CAMERA
“LUMIX G VARIO 7–14 mm/F4.0 ASPH.”
Focal length f=7 mm to 14 mm
(35 mm film camera equivalent: 14 mm to 28 mm)
Aperture type 7 leaf shutters/iris diaphragm/circular diaphragm
Aperture range F4.0
Minimum aperture value F22
Lens construction 16 elements in 12 groups (2 aspherical lenses, 4 ED lenses)
In focus distance 0.25 m to ¶ (from the focus distance reference line)
Maximum image magnification 0.08k (35 mm film camera equivalent: 0.15k)
Optical image stabilizer Not available
Mount “Micro Four Thirds Mount”
Angle of view 114x (Wide) to 75x (Tele)
Filter diameter Filter non-compatible
Max. diameter 70 mm (lens hood section)
Overall length Approx. 83.1 mm
(from the tip of the lens hood to the base side of the lens mount)
Mass Approx. 300 g
