6
PT-L780NT
Wireless Portable LCD Projector
S P E C F I L E
as of July 2002
Standard setting-up positions
unit: mm
NOTE:
Illustrations show the projector installed using
optional celing bracket ET-PK780.
L: Projection distance between the screen
and the surface of the lens
Note: This illustration is not drawn to scale.
1.0 m
40˝ (3.3´)
1.3 m
50˝ (4.2´)
1.5 m
60˝ (5.0´)
1.8 m
70˝ (5.8´)
2.0 m
80˝ (6.7´)
2.3 m
90˝ (7.5´)
2.5 m
100˝ (8.3´)
3.0 m
120˝ (10.0´)
3.8 m
150˝ (12.5´)
5.1 m
200˝ (16.7´)
6.4 m
250˝ (20.8´)
7.6 m
300˝ (25.0´)
Screen size
(4:3)
min.
1.1 m
3.6´
1.3 m
4.3´
1.6 m
5.2´
1.9 m
6.2´
2.2 m
7.2´
2.4 m
7.9´
2.7 m
8.9´
3.2 m
10.5´
4.0 m
13.1´
5.4 m
17.7´
6.7 m
22.0´
8.1 m
26.6´
With ET-LE10
Throw distance
with supplied lens With ET-LE20 With ET-LE30
recommended*
1.3 m
4.3´
1.7 m
5.6´
2.0 m
6.6´
2.4 m
7.9´
2.7 m
8.9´
3.1 m
10.2´
3.5 m
11.5´
4.2 m
13.8´
5.2 m
17.1´
7.0 m
23.0´
8.8 m
28.9´
10.6 m
34.8´
max.
1.3 m
4.3´
1.7 m
5.6´
2.0 m
6.6´
2.4 m
7.9´
2.7 m
8.9´
3.1 m
10.2´
3.5 m
11.5´
4.2 m
13.8´
5.2 m
17.1´
7.0 m
23.0´
8.8 m
28.9´
10.6 m
34.8´
min.
1.6 m
5.2´
2.0 m
6.6´
2.4 m
7.9´
2.8 m
9.2´
3.2 m
10.5´
3.6 m
11.8´
4.0 m
13.1´
4.8 m
15.7´
6.1 m
20.0´
8.1 m
26.6´
10.1 m
33.1´
12.2 m
40.0´
recommended*
1.9 m
6.2´
2.4 m
7.9´
2.9m
9.5´
3.4 m
11.2´
3.9 m
12.8´
4.4 m
14.4´
4.9 m
16.1´
5.9 m
19.4´
7.4 m
24.3´
9.8 m
32.2´
12.3 m
40.4´
14.8 m
48.6´
max.
2.0 m
6.6´
2.6 m
8.5´
3.1 m
10.2´
3.6 m
11.8´
4.2 m
13.8´
4.7 m
15.4´
5.3 m
17.4´
6.3 m
20.7´
7.9 m
25.9´
10.6 m
34.8´
13.3 m
43.6´
16.0 m
52.5´
min.
2.1 m
6.9´
2.7 m
8.9´
3.2 m
10.5´
3.8 m
12.5´
4.3 m
14.1´
4.9 m
16.1´
5.4 m
17.7´
6.6 m
21.7´
8.2 m
26.9´
11.0 m
36.1´
13.8 m
45.3´
16.5 m
54.1´
recommended*
2.5 m
8.2´
3.2 m
10.5´
3.9 m
12.8´
4.5 m
14.8´
5.2 m
17.1´
5.9 m
19.4´
6.5 m
21.3´
7.9 m
25.9´
9.9 m
32.5´
13.3 m
43.6´
16.6 m
54.5´
20.0 m
65.6´
max.
3.3 m
10.8´
4.2 m
13.8´
5.0 m
16.4´
5.9 m
19.4´
6.8 m
22.3´
7.7 m
25.3´
8.5 m
27.9´
10.3 m
33.8´
12.9 m
42.3´
17.2 m
56.4´
21.6 m
70.9´
26.0 m
85.3´
min.
3.4 m
11.2´
4.2 m
13.8´
5.0 m
16.4´
5.8 m
19.0´
6.6 m
21.7´
7.4 m
24.3´
8.2 m
26.9´
9.9 m
32.5´
12.3 m
40.4´
16.3 m
53.5´
20.4 m
66.9´
24.4 m
80.1´
recommended*
4.6 m
15.1´
5.8 m
19.0´
6.9 m
22.6´
8.1 m
26.6´
9.2 m
30.2´
10.4 m
34.1´
11.5 m
37.7´
13.8 m
45.3´
17.3 m
56.8´
23.0 m
75.5´
28.7 m
94.2´
34.5 m
113.2´
max.
4.6 m
15.1´
5.8 m
19.0´
6.9 m
22.6´
8.1 m
26.6´
9.2 m
30.2´
10.4 m
34.1´
11.5 m
37.7´
13.8 m
45.3´
17.3 m
56.8´
23.0 m
75.5´
28.7 m
94.2´
34.5 m
113.2´
* Recommended throw distances when the unit is set up as a fixed-type projector.
• Figures shown above are approximate.
• Images may be distorted when the throw distance is adjusted to the minimum.
Edge of projected image
L
L
Projected image
Projected image
Edge of projected image
