Panasonic H-VS014140 - Manual (Page 6)

6
VQT2C39
∫Detaching the Lens
≥ Check that the camera is turned off.
Press the lens release button C while
turning the lens as far as possible in the
direction of the arrow to detach it.
• Attach the lens rear cap so
that the lens contact point
does not get scratched.
• Attach the body cap to the
camera so no dirt or dust will
get inside the main unit.
∫Attaching and Detaching the Lens Cap
≥ Be careful not to lose
the lens cap.
∫ Attaching the Lens Hood
(Supplied Accessory)
Insert the lens hood into the lens with the
short sides at the top and bottom, and
turn in the direction of the arrow until it
stops.
D: Fit to the mark
∫ Temporarily Storing the Lens Hood
1 Turn the lens hood in the direction of the
arrow to detach it.

H-VS014140E-VQT2C39.book 6 ページ ２００９年３月１３日 金曜日 午前１０時１３分
