Panasonic HX-A500H - Manual (Page 21)

21
(ENG) SQT0251
4
Pass the band through the band hole.
5
Attach the band to the hard surface of
the hook and loop fastener to fasten
the band to your arm.
≥ When fastening the main unit, try not to drop the
camera unit to avoid a shock and try not to
scratch the lens.
∫ About the Armband Case
The Armband Case can be used as a portable holder.
≥ The camera unit can be stored in the camera pocket B , and the camera/main unit connection
cable can be bundled with the band A .
≥ When fastening to your arm, remove the camera unit from the Armband Case.
≥ When removing the camera/main unit from the Armband Case, avoid pulling the camera/main
unit connection cable.
≥ Do not forcibly bend or pull the cable. Be extra careful in low temperatures, which cause the
cable to become fairly inflexible.
≥ Optional accessories will be handy in various scenes. ( l 33)

D Hard surface of the hook and loop
fastener


