American Dryer Corp. AD-75D II - Manual (Page 37)

35
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 810047 1 Direct Spark Ignition (DSI) Burner Box 4-Tube Burner
** 882802 1 Burner Assembly (4-tube) Natural Gas
** 882801 1 Burner Assembly (4-tube) Liquid Propane (L.P.) Gas
2 141105 4 Large Burner Tube
3 141210 1 3/4” Direct Spark Ignition (DSI) Manifold (4-port)
4 318714 1 Bracket For Horizontal Facing Gas Valve
5 150300 9 #10 x 1/2” Hex Washer TEK Screw
6* 140820 4 Natural Orifice #29
140805 4 Liquid Propane (L.P.) Gas Orifice #47
7 150108 4 #8-32 x 1/2” Pan Head Machine Screw
8 142707 1 1/2” x 1-1/2” B.I. Nipple
9 151001 4 #8-32 Pal Nut
10 128927 1 24 VAC Gas Valve
11 150309 5 #10-16 x 1/2” Hex Head TEK Crimptite Screw
12 142506 1 1/2” Street Elbow
13 152013 2 #6-32 Hex Nut 1/4” ATF Zinc Plated
14 810030 1 Johnson Controls Direct Spark Ignition (DSI) Module Mounting Bracket
15 128935 1 Direct Spark Ignition (DSI) Module with Three Tries
16 809309 1 Ignitor Probe Assembly with 19” Leads
17 142600 1 1/2” Black Union
18 319704 1 Hi-Limit Mounting Bracket
19 151000 2 #6-32 Pal Nut
20 150001 2 #6-32 x 1/2” Phillips Round Head Machine Screw
21 130201 1 330º Hi-Limit Manual Reset
22 318700 1 Pipe Bracket (bent)
23 143000 1 3/4” to 1/2” Reducing Coupling
24 154004 1 Twin Speed Nut
25 802799 1 Sail Switch Box Cover and Bracket ONLY
26 122200 1 Sail Switch ONLY
27 150303 2 #4 x 3/4” Pan Head “A” Machine Screw
28 105500 1 Sail Switch Actuator Rod
29 319202 1 Sail Switch Damper (flat)
30 154002 1 1/8” Push On Fastener
31 142809 1 1/2” x 29-1/8” Pipe
- 881231 1 AD-75D II Liquid Propane (L.P.) Conversion Kit ... Not Illustrated
* Orifices are at sea level for elevations above 2,000 feet. Consult the factory.
** Orifices are not included.
4-Tube Burner Assembly
