Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly
Illus. No.
Part No.
Qty.
Description
1
100114
1
4L-630 V-Belt (motor to idler)
2
100701
1
3/16” x 3/16” x 1” Key
3
101133
1
5/8” x 2-1/4” Motor Pulley (60 Hz Only)
101130
1
5/8” x 2-1/2” Motor Pulley (60 Hz Only)
4
150501
4
5/16-18 x 3/4” Hex Head Machine Bolt
5
153002
4
5/16” Lock Washer
6
153001
4
5/16” Flat Washer
7*
100073
1
1 HP 120/208/230v 1ø 60 Hz Totally Enclosed, Fan-Cooled (T.E.F.C.)
Motor with Plug (56Z frame)
8
122701
8
Socket Terminal ONLY
122801
1
Pin/Socket Extraction Tool
9
137030
1
8-Pin Housing Connector
10
152004
4
5/16-18 Hex Nut
11
153002
4
5/16” Lock Washer
12
153001
4
5/16” Flat Washer
13
117604
4
Neoprene Sponge Tape (sold by the foot)
14
154000
4
5/16-18 Tinnerman Nut
15
800919
1
Non-Reversing Motor Mount ONLY (56Z frame)
803992*
1
1 HP 120/230v 1ø 60 Hz Totally Enclosed, Fan-Cooled (T.E.F.C.)
Motor Mount Assembly with Plug Complete
(includes illus. nos. 2 through 7 and 13 through 20)
803953
1
3/4 HP 230v 1ø 50 Hz Non-Reversing Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
803955*
1
1 HP 230/380/460v 3ø 60 Hz Non-Reversing Totally Enclosed,
Fan-Cooled (T.E.F.C.) Motor Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
803958*
1
1 HP 230/380/460v 3ø 50 Hz Non-Reversing Totally Enclosed,
Fan-Cooled (T.E.F.C.) Motor Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
16
153051
1
3/4” S.A.E. Flat Washer
17
882670
1
16” Fab Fan Assembly (rivets)
18
100714
1
3/16” x 3/16” x 1-7/8” Key
19
153050
2
1/2” S.A.E. Flat Washer
20
152006
2
1/2-20 Left Hand Jam Nut
21
120200
1
3/8” x 90° Connector
22
100075*
1
1 HP 208/230/240/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor
100076
1
3/4 HP 230v 1ø Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor
56Z Frame (50 Hz Only)
*
Specify voltage when ordering.
