29
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 100114 1 4L-630 V-Belt (motor to idler)
For Reversing Gas and Electric Models ONLY
100109 1 4L-650 V-Belt (motor to idler)
For Reversing Steam Models ONLY
2 100701 1 3/16” x 3/16” x 1” Key
3 101130 1 5/8” x 2-1/2” Motor Pulley (60 Hz Only)
101139 1 5/8” x 2-3/4” Motor Pulley (50 Hz Only)
4 120200 1 3/8” x 90° Connector
5 181003 1 1/2 HP 208/230/380/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor (56Z frame)
6 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
7 153002 4 5/16” Lock Washer
8 153001 4 5/16” Flat Washer
9* 100075 1 1 HP 208/230/240/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor with 3/4” Shaft (56Z frame)
10 120200 1 3/8” x 90° Connector
11 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
12 153002 4 5/16” Lock Washer
13 153001 4 5/16” Flat Washer
14 154000 8 5/16-18 Tinnerman Nut
15 152004 7 5/16-18 Hex Nut
16 153002 7 5/16” Lock Washer
17 153001 7 5/16” Flat Washer
18 800920 1 Reversing Motor Mount ONLY (56Z frame)
803952** 1 60 Hz Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount
Assembly Complete
(includes illus. nos. 2 through 14 and 18 through 24)
803987** 1 50 Hz Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount
Assembly Complete
(includes illus. nos. 2 through 14 and 18 through 24)
19 117604 4 Neoprene Sponge Tape (sold by the foot)
For Models Mfd. as of August 6, 1998
20 153051 1 3/4” S.A.E. Flat Washer
21 100702 1 1/8” x 1/8” x 1-1/2” Key
22 882670 1 16” Fab Fan Assembly (rivets)
881428 1 13” Impellor with 3/4” Bore
(for models mfd. prior to March 1, 1995)
23 153050 *** 1/2” S.A.E. Flat Washer
24 152006 2 1/2-20 Left Hand Jam Nut
* Check part number on motor data label to verify correct motor.
** Specify voltage when ordering.
*** As required.
Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly
