Sony DCR-TRV950 - Manual (Page 243)

243
Additional Information
Specifications
General
Power requirements
7.2 V (battery pack)
8.4 V (AC power adaptor)
Average power consumption
(when using the battery pack)
During camera recording using
LCD
6.3 W
Viewfinder
4.9 W
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to + 60°C
(–4°F to + 140°F)
Dimensions (Approx.)
93 Ч 99 Ч 202 mm
(3 3/4 Ч 4 Ч 8 in.) (w/h/d)
Mass (Approx.)
DCR-TRV950: 970 g (2 lb 2 oz)
DCR-TRV940: 960 g (2 lb 1 oz)
main unit only
DCR-TRV950: 1.1kg (2 lb 6 oz)
DCR-TRV940: 1.1kg (2 lb 6 oz)
including the battery pack
NP-FM50, cassette DVM60 and
lens cap, Shoulder strap
Supplied accessories
See page 14.
AC power adaptor
Power requirements
100 – 240 V AC, 50/60 Hz
Power consumption
23 W
Output voltage
DC OUT: 8.4 V, 1.5 A in the
operating mode
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to + 60°C
(–4°F to + 140°F)
Dimensions (approx.)
125 Ч 39 Ч 62 mm
(5 Ч 1 9/16 Ч 2 1/2 in.) (w/h/d)
excluding projecting parts
Mass (approx.)
280 g (9.8 oz)
excluding power cord
Battery pack
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
8.5 Wh (1 180 mAh)
Dimensions (approx.)
38.2 Ч 20.5 Ч 55.6 mm
(1 9/16 Ч 13/16 Ч 2 1/4 in.)
(w/h/d)
Mass (approx.)
76 g (2.7 oz)
Type
Lithium ion
“Memory Stick”
Memory
Flash memory
8MB: MSA-8A
Operating voltage
2.7 – 3.6 V
Power consumption
Approx. 45 mA in the operating
mode
Approx. 130 µA in the standby
mode
Dimensions (approx.)
50 Ч 2.8 Ч 21.5 mm
(2 Ч 1/8 Ч 7/8 in.) (w/h/d)
Mass (approx.)
4 g (0.14 oz)
Design and specifications are
subject to change without notice.
