Sony STR-DA2800ES User Manual
Page 32
32
US
A
HDMI cable (not supplied)
B
Optical digital cord (not supplied)
C
Audio cord (not supplied)
D
Video cord (not supplied)
E
Component video (not supplied)
*
You can output the satellite tuner/cable box’s sound (multi-channel surround sound) from the receiver only
by connecting the satellite tuner/cable box with an HDMI cable.
** If you want to output multi-channel surround sound from the receiver, use B for the audio connection.
Notes
• When connecting optical digital cords, insert the plugs straight until they click into place.
• Do not bend or tie optical digital cords.
A
Audio cord (not supplied)
B
Video cord (not supplied)
Satellite tuner/Cable
box type
Required cable (cord)
Video
Audio
HDMI equipped*
A
–
Non-HDMI equipped
E
or D
B
or C**
Connections required for watching content recorded on video tapes
VCR
A
B
Audio signals
Video signals
