28
MDR-IF4000
Ref. No.
Part No.
Description
Remarks
Ref. No.
Part No.
Description
Remarks
< IC >
< COIL >
L001
1-469-525-91 INDUCTOR
10uH
L002
1-469-524-91 INDUCTOR
4.7uH
L003
1-412-002-31 INDUCTOR
4.7uH
L004
1-414-760-21 INDUCTOR, FERRITE BEAD
L101
1-414-760-21 INDUCTOR, FERRITE BEAD
L102
1-414-760-21 INDUCTOR, FERRITE BEAD
L103
1-469-524-91 INDUCTOR
4.7uH
L104
1-469-524-91 INDUCTOR
4.7uH
L105
1-414-760-21 INDUCTOR, FERRITE BEAD
L106
1-414-594-11 INDUCTOR, FERRITE BEAD
L107
1-469-524-91 INDUCTOR
4.7uH
L108
1-414-760-21 INDUCTOR, FERRITE BEAD
L109
1-469-526-91 INDUCTOR
22uH
L110
1-414-760-21 INDUCTOR, FERRITE BEAD
L111
1-414-760-21 INDUCTOR, FERRITE BEAD
L112
1-414-760-21 INDUCTOR, FERRITE BEAD
L113
1-414-760-21 INDUCTOR, FERRITE BEAD
L201
1-469-526-91 INDUCTOR
22uH
L301
1-469-524-91 INDUCTOR
4.7uH
L302
1-414-760-21 INDUCTOR, FERRITE BEAD
L303
1-414-760-21 INDUCTOR, FERRITE BEAD
L304
1-469-524-91 INDUCTOR
4.7uH
L305
1-414-760-21 INDUCTOR, FERRITE BEAD
L306
1-414-760-21 INDUCTOR, FERRITE BEAD
< TRANSISTOR >
Q101
8-729-928-81 TRANSISTOR
DTC144EE
Q301
8-729-043-69 TRANSISTOR
UN2225-(TX).S0
Q302
8-729-043-69 TRANSISTOR
UN2225-(TX).S0
< RESISTOR >
R001
1-216-825-11 METAL CHIP
2.2K
5%
1/10W
R002
1-216-821-11 METAL CHIP
1K
5%
1/10W
R003
1-216-839-11 METAL CHIP
33K
5%
1/10W
R004
1-216-823-11 METAL CHIP
1.5K
5%
1/10W
R101
1-216-821-11 METAL CHIP
1K
5%
1/10W
R102
1-216-821-11 METAL CHIP
1K
5%
1/10W
R103
1-216-821-11 METAL CHIP
1K
5%
1/10W
R104
1-218-664-11 METAL CHIP
68
0.5%
1/10W
R106
1-216-833-11 METAL CHIP
10K
5%
1/10W
R107
1-216-833-11 METAL CHIP
10K
5%
1/10W
R108
1-216-821-11 METAL CHIP
1K
5%
1/10W
R109
1-216-827-11 METAL CHIP
3.3K
5%
1/10W
R110
1-216-820-11 METAL CHIP
820
5%
1/10W
R111
1-216-829-11 METAL CHIP
4.7K
5%
1/10W
R112
1-216-833-11 METAL CHIP
10K
5%
1/10W
R201
1-216-821-11 METAL CHIP
1K
5%
1/10W
R202
1-216-821-11 METAL CHIP
1K
5%
1/10W
R301
1-216-843-11 METAL CHIP
68K
5%
1/10W
R302
1-216-833-11 METAL CHIP
10K
5%
1/10W
R306
1-216-843-11 METAL CHIP
68K
5%
1/10W
R307
1-216-833-11 METAL CHIP
10K
5%
1/10W
R308
1-216-833-11 METAL CHIP
10K
5%
1/10W
R501
1-216-833-11 METAL CHIP
10K
5%
1/10W
R502
1-216-817-11 METAL CHIP
470
5%
1/10W
< VARIABLE RESISTOR >
RV201
1-223-517-11 RES, VAR, CARBON
50K/50K
(VOL )
< VIBRATOR >
X101
1-795-485-21 VIBRATOR, CRYSTAL (SMD) (12.288MHz)
******************************************************
ACCESSORIES
**********
1-756-316-22 BATTERY, NICKEL.HYDROGEN (US, Canadian)
1-756-316-32 BATTERY, NICKEL.HYDROGEN (AEP, KR)
2-345-751-12 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH, KOREAN)
2-345-751-21 MANUAL, INSTRUCTION
(GERMAN, DUTCH, ITALIAN, PORTUGUESE)
(AEP)
RX: Suffix-12
