Page 20
20
MDR-IF4000
Ref. No.
Part No.
Description
Remarks
Ref. No.
Part No.
Description
Remarks
C005
1-124-779-00 ELECT CHIP
10uF
20%
16V
C006
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C007
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C008
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C009
1-124-778-00 ELECT CHIP
22uF
20%
6.3V
C010
1-162-959-11 CERAMIC CHIP
330PF
5%
50V
C011
1-162-969-11 CERAMIC CHIP
0.0068uF
10%
25V
C012
1-162-969-11 CERAMIC CHIP
0.0068uF
10%
25V
C013
1-162-970-11 CERAMIC CHIP
0.01uF
10%
25V
C014
1-162-927-11 CERAMIC CHIP
100PF
5%
50V
C015
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C016
1-162-964-11 CERAMIC CHIP
0.001uF
10%
50V
C017
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C101
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C102
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C103
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C104
1-124-779-00 ELECT CHIP
10uF
20%
16V
C105
1-125-837-91 CERAMIC CHIP
1uF
10%
6.3V
C107
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C108
1-126-205-11 ELECT CHIP
47uF
20%
6.3V
C109
1-125-837-91 CERAMIC CHIP
1uF
10%
6.3V
C110
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C111
1-162-917-11 CERAMIC CHIP
15PF
5%
50V
C112
1-125-837-91 CERAMIC CHIP
1uF
10%
6.3V
C113
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C115
1-162-917-11 CERAMIC CHIP
15PF
5%
50V
C116
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C117
1-104-851-11 TANTAL. CHIP
10uF
20%
10V
C118
1-125-837-91 CERAMIC CHIP
1uF
10%
6.3V
C119
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C120
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C121
1-124-778-00 ELECT CHIP
22uF
20%
6.3V
C123
1-162-970-11 CERAMIC CHIP
0.01uF
10%
25V
C124
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C125
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C126
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C130
1-164-227-11 CERAMIC CHIP
0.022uF
10%
25V
C201
1-104-851-11 TANTAL. CHIP
10uF
20%
10V
C202
1-104-851-11 TANTAL. CHIP
10uF
20%
10V
C203
1-162-966-11 CERAMIC CHIP
0.0022uF
10%
50V
C204
1-126-208-21 ELECT CHIP
47uF
20%
4V
C205
1-162-966-11 CERAMIC CHIP
0.0022uF
10%
50V
C206
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C207
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C208
1-124-779-00 ELECT CHIP
10uF
20%
16V
C210
1-125-837-91 CERAMIC CHIP
1uF
10%
6.3V
C301
1-162-917-11 CERAMIC CHIP
15PF
5%
50V
C302
1-104-851-11 TANTAL. CHIP
10uF
20%
10V
C303
1-162-927-11 CERAMIC CHIP
100PF
5%
50V
C304
1-104-851-11 TANTAL. CHIP
10uF
20%
10V
C305
1-104-912-11 TANTAL. CHIP
3.3uF
20%
16V
C306
1-137-934-91 TANTAL. CHIP
47uF
20%
10V
C307
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C308
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C309
1-162-917-11 CERAMIC CHIP
15PF
5%
50V
C310
1-104-851-11 TANTAL. CHIP
10uF
20%
10V
C311
1-104-851-11 TANTAL. CHIP
10uF
20%
10V
C312
1-162-927-11 CERAMIC CHIP
100PF
5%
50V
C313
1-104-851-11 TANTAL. CHIP
10uF
20%
10V
C314
1-104-912-11 TANTAL. CHIP
3.3uF
20%
16V
C315
1-137-934-91 TANTAL. CHIP
47uF
20%
10V
C316
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C317
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C501
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
C502
1-110-569-21 TANTAL. CHIP
47uF
4V
C509
1-107-826-11 CERAMIC CHIP
0.1uF
10%
16V
< DIODE >
D101
8-719-988-61 DIODE 1SS355TE-17
D102
8-719-988-61 DIODE 1SS355TE-17
D103
8-719-988-61 DIODE 1SS355TE-17
D104
8-719-988-61 DIODE 1SS355TE-17
D502
8-719-059-98 DIODE SLR-342VC3F (POWER)
< IC >
< COIL >
L001
1-469-525-91 INDUCTOR
10uH
L002
1-469-524-91 INDUCTOR
4.7uH
L003
1-412-002-31 INDUCTOR
4.7uH
L004
1-414-760-21 INDUCTOR, FERRITE BEAD
L101
1-414-760-21 INDUCTOR, FERRITE BEAD
L102
1-414-760-21 INDUCTOR, FERRITE BEAD
L103
1-469-524-91 INDUCTOR
4.7uH
L104
1-469-524-91 INDUCTOR
4.7uH
L105
1-414-760-21 INDUCTOR, FERRITE BEAD
L106
1-414-594-11 INDUCTOR, FERRITE BEAD
L107
1-469-524-91 INDUCTOR
4.7uH
L108
1-414-760-21 INDUCTOR, FERRITE BEAD
L109
1-469-526-91 INDUCTOR
22uH
L201
1-469-526-91 INDUCTOR
22uH
L301
1-469-524-91 INDUCTOR
4.7uH
L302
1-414-760-21 INDUCTOR, FERRITE BEAD
L303
1-414-760-21 INDUCTOR, FERRITE BEAD
L304
1-469-524-91 INDUCTOR
4.7uH
L305
1-414-760-21 INDUCTOR, FERRITE BEAD
L306
1-414-760-21 INDUCTOR, FERRITE BEAD
< TRANSISTOR >
Q101
8-729-928-81 TRANSISTOR DTC144EE
Q301
8-729-043-69 TRANSISTOR UN2225-(TX).S0
Q302
8-729-043-69 TRANSISTOR UN2225-(TX).S0
< RESISTOR >
R001
1-216-825-11 METAL CHIP
2.2K
5%
1/10W
R002
1-216-821-11 METAL CHIP
1K
5%
1/10W
R003
1-216-839-11 METAL CHIP
33K
5%
1/10W
R004
1-216-823-11 METAL CHIP
1.5K
5%
1/10W
R101
1-216-821-11 METAL CHIP
1K
5%
1/10W
