Sony KE-50XS910 - Manual (Page 18)

16
Se
tu
p
TV Controls and Connectors
Front Panel
Item Description
1 PICTURE OFF
LED When lit, indicates that the Picture Off feature is activated.
For details, see page 65.
2 TIMER LED When lit, indicates one of the timers is set. When the timer
is set, this LED will remain lit even if the TV set is turned
off. For details, see page 97.
3 STANDBY LED Lights up in red when the TV is in standby mode. The LED
does not light up when the main power is turned off. If the
LED blinks continuously, this may indicate the display unit
needs servicing (see “Contacting Sony” on page 101).
4 POWER LED Lights up in green when the TV set is turned on.
5 Infrared
Receiver (IR) Receives IR signals from the TV’s remote control.
PICTURE OFF TIMER STANDBY POWER
1234 5
