35
W
IRING
D
IAGRAM
Model 926307, 308, 500, 501
Item Part No. Qty. Description
1 00432500 1 Light, Halogen Assembly
2 07532900 2 Warmer, Hand with Terminal (Recommend Fast Drying Epoxy for Installation)
3 AR Battery Recommend 240 Minimum CCA at 0° F. Size U1R or U1L
4 03679000 1 Solenoid
5 00432400 1 Harness, Wire-LT, HW, 12V
6 52709300 1 Switch Assembly
7 00524700 1 15 AMP Fuse
8 02485700 1 Switch, On/Off Hand Warmer
BLACK
B ROWN
KEY
SWITCH
MAGNETO
RED
D.C. CHARGE
A.C. LIGHTING
BATTERY
RED
STARTER
BLACK
RED
RED
YELLOW
WHITE / BLACK
M
G
B
A
A
S
R
RED
1
HEAD LIGHT
BLACK
2
YELLOW
BROWN / ORANGE YELLOW
BLACK
1 1
2 2
1 1
2 2
HAND
WARMERS
BLACK
STARTER
SOLENOID
FUSE
15 AMP
A B
COIL 2 COIL 1
BR
O
WN/ORANGE
HAND WARMER
SWITCH
LEFT
RIGHT
4
1
2
3
4
1
2
3
BLACK
PURPLE
GROUND
ENGINE
PS0672
1
2
2
4
5
6
7
3
8
