Continuity diagram, Ontinuity, Iagram – Ariens Sno-Thro 926300 - 11526DLE User Manual
Page 34
34
C
ONTINUITY
D
IAGRAM
Model 926307, 308, 500, 501
PS0841
The diagrams below show the various states of connection for electrical components.
The solid lines on switchs show continuity.
NOTE: All switches are viewed from the rear.
S
A
M
B
R
G
S
A
M
B
R
G
S
A
M
B
R
G
OFF
RUN
START
HAND WARMER
OFF
HAND WARMER
ON
NOT ENERGIZED
ENERGIZED
Key Switch
(02739600)
Hand Warmer Switch
(02485700)
Solenoid (Top View)
(03679000)
