For PC Input

• “Auto Wide”, “4:3 Default”, “Display Area” and “Vertical Size” are not available for PC input.
• If there is no signal currently being input, none of the “Screen” settings options, except for “PAP Setting” and “Multi Display”

can be selected.

• When the input is via HDMI 1/HDMI 2, “Auto Adjustment”, “Phase” and “Pitch” are not available for PC input.

When input is switched to PC input source, the
“Screen” settings specific for PC input are applied.
The “Screen” settings for a PC include the following
options:

Wide Mode

“Normal”: Select to display the picture in its original size.
“Full 1”: Select to enlarge the picture to fill the display area in the vertical direction,
keeping its original horizontal-to-vertical aspect ratio. A black frame will appear on
the surrounding of the picture.
“Full 2”: Select to enlarge the picture to fill the display area.

You cannot set the “Wide Mode” while using the “PAP” function or the “Multi Display”
function.

Auto Adjustment

Select to automatically adjust the display position and phase of the picture when the
display receives an input signal from the connected PC.
Note that “Auto Adjustment” may not work well with certain input signals. In such
cases, manually adjust the options below.

Phase

Select to adjust the phase when the screen flickers.

Pitch

Select to adjust the pitch when the picture has unwanted vertical stripes.

Horizontal Shift

Allows you to move the position of the picture left and right in the window. Press
G/g and press

to choose a correction.

Vertical Shift

Allows you to move the position of the picture up and down in the window. Press
F/f and press

to choose a correction.

Reset

Resets the following settings; “Phase”, “Pitch”, “Horizontal Shift” and “Vertical
Shift” to the default settings.

PAP Setting

See “PAP Setting” for video input (page 26).

Multi Display

See “Multi Display” for video input (page 27).

Notes

Screen

Wide Mode : Normal

Auto Wide :

4:3 Default :
Display Area :

Auto Adjustment
Phase :

Pitch :

Horizontal Shift :

Vertical Shift :

Vertical Size :

Reset
PAP Setting
Multi Display

Exit:

Back:

MENU

HD15 RGB

Sel

Set

Note
