87

Chapter 5

23 (CN19)

USB Connector

24 (U22)

BIOS ROM

25 (U23)

EC PC97551

26 (BT1)

RTC Battery

27 (CN20)

DDR SO-DIMM Socket1

28 (U25)

LAN PHY RTL8201CP

29 (CN21)

DDR SO-DIMM Socket2

30 (U26)

Southbridge 963L

31 (CN22)

PCMCIA Connector

32 (CN23)

HDD Connector

33 (CN24)

USB Connector

34 (CN26)

LineOut Jack

35 (CN25)

Microphone Jack

36 (CN27)

LineIn Jack

37 (SW2)

WLAN Button

38 (SW3)

Bluetooth button

39 (LED2)

Battery LED

40 (LED1)

Power LED

41 (U30)

Audio Codec ALC203

42 (CN13)

FAN Connector
