61 Chapter 3
7. Remove the two screws securing the SW DJ board assembly.
8. Remove the SW DJ board assembly from the lower case.
9. Remove the two screws securing the SW DJ board and SW DJ board bracket.
10. Then remove the SW DJ board.
Removing the Audio Board
1. See “Removing the Battery” on page 50.
2. See “Removing the Middle Cover” on page 53.
3. See “Removing the Keyboard” on page 53.
4. See “Removing the Power Board” on page 58.
5. See “Removing the Upper Case Assembly” on page 58.
6. See “Removing the Speaker Set” on page 60.
7. See “Removing the SW DJ Board Assembly” on page 60.
8. Remove the screw securing the audio board.
9. Detach the audio board FFC.
10. Release the CIR receiver cable.
11. Then detach the audio board.
Removing the VGA Thermal Module
1. See “Removing the Battery” on page 50.
