Disassembly Procedure Flowchart
The flowchart on the succeeding page gives you a graphic representation on the entire disassembly sequence
and instructs you on the components that need to be removed during servicing. For example, if you want to
remove the main board, you must first remove the keyboard, then disassemble the inside assembly frame in
that order.
Start
Battery
HDD Module Hinge Caps
HDD
LCD Module
*6
Keyboard
Lower Case
Assembly
*3
*3
*11
*4
Dimm Cover
Memory
*2
*2
Launch Board
Modem Cover
Modem Board
*1
*2
CPU
RTC Battery
Mini PCI Card
Plate
Thermal
Module
*4
*3
HDD Holder
*2
*2
Middle Cover
Upper Case
Assembly
Wireless LAN
Antenna
Touchpad
Cover
Touchpad
Button Pad
Touchpad
Upper Case
Touchpad
Cable
Touchpad
Scroll Key
FDD Module
VGA Heatsink
Plate
CPU Heatsink
Plate
ODD Support
Bracket
HDD Bracket ODD Module
Main Board
DC Board PCMCIA Slot
Speaker Set
ODD Bracket ODD
Wireless LAN
Card
Disconnect
Wireless LAN
Antenna
*4 *2
*3 *1 *1 *4
*2
*4
*2 *4
*2
