15

Getting Started

Installing the battery pack

Be sure to set the POWER switch to OFF (CHG) when replacing the battery pack.

(1) While sliding the BATT (battery) release lever in the direction of the arrow 1,

slide the battery terminal cover in the direction of the arrow 2.

(2) Slide the battery pack down until it clicks.

To remove the battery pack

Remove the battery pack while sliding the BATT (battery) release lever.

1

Step 1 Preparing the power source

BATT release lever

2

1

2
