Maintenance

802734

Reinstallation of Shipping Materials

To prevent damage while moving the washer, the

shipping materials MUST be reinstalled.

• Disconnect washer from electrical supply.
• While supporting the front access panel, remove

two screws from the bottom edge of the panel.

• Gently lower the panel to remove it from the

washer.

• Place the shock sleeves on all four shock

• Insert hooked end of shipping brace into the open

slot of the motor mount. Refer to Figure 48.

• Attach the brace with the five bolts and washers.

• Reinstall front access panel.

Figure 48

Refer to Installation section, step 6 for proper

procedures whenever the washer is moved.

Cleaning Foreign Object Trap

The washer’s pump has a trap that may collect foreign

objects. The trap may need to be cleaned if water is

draining slower than usual. To clean:

• Disconnect washer from electrical supply.
• While supporting the front access panel, remove

two screws from the bottom edge of the panel.

• Gently lower the panel to remove it from the

washer.

NOTE: The pump may have some water in it. Use a

rag or a container to catch water. If the wash drum

is full of water, use a wet/dry shop vacuum to catch

the water.

• With rag or vacuum ready, unscrew the cap on

the left side of the pump and remove trap.

• Clean the debris from the trap.
• Reinstall the trap and access panel.
• Reconnect washer to electrical supply.

FLW2124N

Shock Sleeves

Motor Mount

Hooked End of Shipping Brace

Bolts and Lockwashers
