© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

Installation

13

802734

Step 6: Remove the Shock Sleeves and
Shipping Brace

1. Remove panel.

Figure 10

2. Remove brace. Five bolts secure brace to

machine. For easier removal, remove in order

shown.

Figure 11

3. Remove shock sleeves.

Figure 12

4. Replace panel.

Figure 13

Figure 14

IMPORTANT: The shipping brace, bolts,

lockwashers and shock sleeves should be saved and

MUST be reinstalled whenever the unit is moved

more than four feet. Do not lift or transport unit

from front or without shipping materials installed.

Refer to the User’s Guide for proper instructions

on reinstalling the shipping materials.

IMPORTANT: DO NOT tip washer more than

6 inches (152.4 mm) in any direction after shipping

brace has been removed. Shock absorbers may

separate and damage to washer may result. For

leveling purposes, the washer may be tilted a

maximum of 6 inches (152.4 mm) in any direction.

FLW2269N

FLW2270N

FLW2271N

FLW2269N

1

5

2

3

4

FLW2271N

FLW2272N

FLW2268N

FLW2272N

FLW2268N
