High end systems/lightwave research™ (release #1) – elektraLite CP3 User Manual
Page 17

16
HIGH END SYSTEMS/LIGHTWAVE RESEARCH™ (RELEASE #1)
TRACKSPOT®
CP-3 MODE DIPSWITCH # 7 & 8 OFF
UNIT #
DMX CH.
DIPSWITCHES ‘ON’
NOTES
1
1
none
Personality DIPs 3 & 5 ON
2
9
4
Personality DIPs 3 & 5 ON
3
17
5
Personality DIPs 3 & 5 ON
4
25
4,5
Personality DIPs 3 & 5 ON
5
33
6
Personality DIPs 3 & 5 ON
6
41
4,6
Personality DIPs 3 & 5 ON
7
49
5,6
Personality DIPs 3 & 5 ON
8
57
4,5,6
Personality DIPs 3 & 5 ON
TECHNOBEAM®
CP-3 MODE DIPSWITCH # 7 OFF & 8 ON
(reduced/14 channel mode)
UNIT #
DMX CH.
DIPSWITCHES ‘ON’
NOTES
1
1
N/A
All addresses are set digitally on Technobeams.
2
17
N/A
3
33
N/A
Please refer to the Technobeam operators guide
4
49
N/A
for instructions on DMX address settings.
5
65
N/A
6
81
N/A
7
97
N/A
8
113
N/A
