elektraLite CP3 User Manual
Page 16

15
ROBOSCAN P-812®
CP-3 MODE DIPSWITCH # 7 & 8 OFF
UNIT #
DMX CH.
DIPSWITCHES ‘ON’
NOTES
1
1
1
2
9
1,4
3
17
1,5
4
25
1,4,5
5
33
1,6
6
41
1,4,6
7
49
1,5,6
8
57
1,4,5,6
ROBOSCAN P-218®
CP-3 MODE DIPSWITCH # 7 OFF & 8 ON
UNIT #
DMX CH.
DIPSWITCHES ‘ON’
NOTES
1
1
1
2
9
1,4
3
17
1,5
4
25
1,4,5
5
33
1,6
6
41
1,4,6
7
49
1,5,6
8
57
1,4,5,6
ROBOSCAN P-518®
CP-3 MODE DIPSWITCH # 7 ON & 8 OFF
UNIT #
DMX CH.
DIPSWITCHES ‘ON’
NOTES
1
1
1
2
9
1,4
3
17
1,5
4
25
1,4,5
5
33
1,6
6
41
1,4,6
7
49
1,5,6
8
57
1,4,5,6
*NOTE: on these Martin™ products there is usually an adapter required for the data cable that reverses
the DMX-512 3 -pin XLR connector pins 2 and 3. Please refer to the fixture’s users guide for specific
product specifications regarding this change. If you require further assistance please contact the Martin
dealer from which the equipment was obtained.
