3. Parts Identification
3.1
Main Unit
Front panel
Film Loading Slot:
The film holder is inserted here.
Option Connector:
The SF-100 slide autofeeder is connected to
this option connector.
Status Display LED:
Shows the scanner status.
Power Switch:
Directly turns the AC power on/off.
Ventilation Holes:
Since air is drawn in through these holes,
make sure that they are not blocked by other
equipment.
Film Slot
Option Connector
Status display LED
Power
Switch
Ventilation Holes
