PerTronix Ignitor II 91589 - Manual

440 E. Arrow Highway, San Dimas, CA. 91773
909-599-5955 www.pertronix.com
LIMITED WARRANTY
Pertronix, Inc. Warrants to the original Purchaser of its solid-state ignition system (product)
that the Ignitor, magnet assembly and wiring (components) shall be free from defects in material and
workmanship for a period of (30) months from the date of purchase.
If within the period of the foregoing warranty Pertronix finds, after inspection, that the
product or any component thereof is defective, Pertronix will, at its option, repair such products
or component or replace them with identical or similar parts PROVIDED that within such period
Purchaser:
Promptly Notifies Pertonix, in writing, of such defects. 1.
Delivers the defective products product or component to Pertronix (ATTN: Warranty) with proof 2.
of purchase date; and
Has installed and used the product in a normal and Proper manner, consistent with Pertronix
3.
printed instructions.
THE FORGOING LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL
OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED, INCLUDING AND IMPLIED
WARRANTY OR MERCHANTABILITY OR FITNESS FOR A PURPOSE.
THE FURNISHING OF A REPAIR OR REPLACEMENT COMPONENTS SHALL CONSTITUTE
THE SOLE REMEDY OF PURCHASER AND THE SOLE LIABILITY OF PerTronix WHETHER
ON WARRANTY, CONTRACT OR FOR NEGLIGENCE, AND IN NO EVENT WILL PerTronix
BE LIABLE FOR MONEY DAMAGES WHETHER DIRECT OR CONSEQUENTIAL.
12-VOLT NEGATIVE GROUND INSTRUCTIONS
GENERAL INFORMATION
See our website (www.pertronix.com) for the latest product information. 1.
IMPORTANT: Read all instructions before starting installation. 2.
WARNING!!! DO NOT USE WITH SOLID CORE IGNITION WIRES. 3.
The Ignitor II ignition can be used in conjunction with most ignition coils rated at 0.45 4.
ohms or greater.
All external resistors must be removed to achieve optimum performance from the Ignitor 5.
II ignition system.
The Ignitor II is compatible as a trigger for most electronic boxes. 6.
WARNING!!! DO NOT USE WITH SOLID CORE SPARK PLUG WIRES.
Remove distributor cap and rotor. Do not disconnect spark plug wires from cap. 1.
Examine cap and rotor for wear or damage. Replace as needed.
Disconnect pick-up coil wires from Ignition coil. Remove screws and lift out 2.
entire pick-up coil assembly. Note: Original control box is not required and
needs to be removed.
Clean all oil and dirt from inside of distributor housing. 3.
Use the original screws to install the Ignitor mounting plate. Make sure that the 4.
cutout in the Ignitor mounting plate is lined up with the wire exit hole in the
distributor housing.
Push the wire grommet into the distributor housing. 5.
Some magnet sleeves may have green tape, DO NOT REMOVE IT. 6.
Install magnet sleeve over distributor shaft, onto Reluctor. 7.
Rotate sleeve until a slight locating position is felt before applying pressure. 8.
With sleeve lined up on reluctor, press down firmly insuring sleeve is fully
seated.
Note: Some Ignitor kits include a spacer ring in the hardware kit. Spacer ring 9.
must be installed between magnet sleeve and rotor.
The wire length inside the distributor can be adjusted through grommet to insure 10.
ample clearance. Make sure all wires are clear of moving parts.
Install the distributor cap and rotor, and make sure all plug wires are attached 11.
securely.
See Wiring Instructions
12.
For Part Number: 91589
04-11 0000
