AR6410T User Guide
The AR6410T 6-channel ultra micro receiver with integrated servos, speed control
and X-Port ™ technology is designed for ultra micro aircraft. Featuring DSM2 ™ /
DSMX ® technology the AR6410T is compatible with all Spektrum ™ , JR ® , E-flite ®
and ParkZone ® 2.4GHz DSM2 technology transmitters.
NOTICE: The AR6410T receiver is not compatible with the DX6 park flyer radio
system.
Features
• 6-channel Ultra micro receiver
• Two integrated linear long throw servos (elevator and rudder)
• Two integrated brushed speed controllers
• Weighs just 4.7 grams
• Compatible with optional Spektrum ultra micro linear servos
• Smart Bind™ technology
• X-Port allows for future expansion
Applications
The AR6410T is designed for ultra micro aircraft and is ideal for scratch-built ultra
micro projects that require dual brushed ESC output. The AR6410T is designed to
utilize a single-cell LiPo battery. Two integrated brushed speed controllers can be
used to power brushed motors up to 2 amps of continuous current. An integrated
X-Port feature allows for future expansion.
Note: When X-Port is active, CH5 and CH6 are not available; however, reversed
aileron (CH2) is still available.
Specifications:
AR6410T
Type: DSM2/DSMX Ultra micro receiver with dual integrated brushed speed
controllers and two linear long throw servos
Channels: 6 channels or 4 channels plus X-Port
Modulation: DSM2/DSMX
Dimension (WxLxH): 27.8 x 38.0 x 8.1mm
Weight: 4.7 g
Input Voltage Range: 3.2 to 4.2V 1-cell LiPo
Antenna Length: 31mm
Resolution: DSM2/DSMX 1024
Compatibility: All DSM2/DSMX aircraft transmitters
Servos
Force: 2.8 oz (79 g)
Stroke: 7.4mm
Speed: 0.14 sec
Speed Controllers:
Type: Two Integrated brushed
Max continuous current: 2.0 amps
