SPEKTRUM DX5e • BEDIENUNGSANLEITUNG
EN
DE
FR
IT
DX5E SENDERAUFBAU
Mode 1
Mode 2
Antenne
Trainerschalter
Kanal 5
Gas und Querruder
Gastrimmung
Querrudertrimmung
Ein/Aus Schalter
Ladebuchse
Mischer
Kanalumpolung
Trainerbuchse
Seitenrudertrimmung
Höhenrudertrimmung
Seitenruder und
Höhenruder
Dual Rate Schalter
Dual Rate Schalter
Trainerschalter
Kanal 5
Antenne
Mischer
Kanalumpolung
Trainerbuchse
Ladebuchse
Ein/Aus Schalter
Querruder und
Höhenruder
Gas und Seitenruder
Höhenrudertrimmung
Seitenrudertrimmung
Gastrimmung
Querrudertrimmung
