17 SPEKTRUM DX2S USER GUIDE
EN
7. With the steering wheel, throttle the trigger in the
desired preset failsafe positions, press the Rolling
Selector to initiate the bind process and to store the
failsafe positions. BIND will flash for a few seconds
then stop, indicating the process is complete. The
LED on the receiver should now be solid, indicating
a successful bind has taken place.
8. Remove the bind plug and store it in a convenient
place.
To return to the main screen press and hold the Rolling
Selector for more than three seconds.
Note: The only time it is necessary to do a
rebind is when different failsafe positions are
desired, e.g. when throttle or steering reversing
has been changed, or if the receiver is to be
bound to a different model memory.
Note: Some Spektrum receivers, like the
SR3000, use a bind button rather than a bind
plug. The binding process is the same with
this receiver, however, instead of inserting the
plug before powering up the receiver, press
and hold the bind button while powering up
the receiver to enter bind mode.
faIlsafe
Failsafe positions are also set during binding. In the
unlikely event that the radio link is lost during use, the
receiver will drive the servos to their preprogrammed
failsafe positions (normally full brakes and straight
steering). If the receiver is turned on prior to turning on
the transmitter, the receiver will enter the failsafe mode,
driving the servos to their preset failsafe positions. When
the transmitter is turned on, normal control is resumed.
Failsafe servo positions are set during binding (see Bind
on the previous page).
TeleMeTry seTTIngs
The Telemetry setting function is used to select a default
screen for display including Main, Telemetry or Roll. It is
also used to access the Telemetry SPEED, BATTERY and
TEMPERATURE sensor settings.
To aCCess The TeleMeTry
seTTIng funCTIon
In the LIST screen use the Rolling Selector to highlight
Tele Setting then press the Rolling Selector.
The TELE SET screen will appear.
To select the default screen, rotate the Rolling Selector to
place the box around Screen: TELE then press the Rolling
Selector. The surrounding box will flash.
• TELE displays the Telemetry screen.
• MAIN always hides the Telemetry screen.
• ROLL allows the roller to select between the
Telemetry and Main screens.
Rotate the Rolling Selector and choose your desired
default screen. (TELE displays the Telemetry screen.
ROLL will allow the Rolling Selector to select between the
Telemetry and Main Screens.) Press the Rolling Selector
to select.
