22
Environmental Specifications
Operating Temperature 0° to 40° C (32° to 104° F)
Storage Temperature -25° to 70° C (-13° to 158° F)
Operating Humidity 5% to 95% non-condensing
Operating Altitude Range Up to 3,048 m (10,000 ft)
Power Specifications 100-240/VAC, 0.8A maximum, 50-60Hz
Twisted Pair Port Specifications
Speed 10 or 100 Mbps (Auto-Negotiation)
Connector RJ-45
Duplex Mode Half- or full-duplex (Auto-Negotiation)
Maximum Distance 100 m (1.25 mi.)
Fiber Optic Port Specifications
Speed 100 Mbps
Duplex Mode Full-duplex
Maximum Distance 2 kilometers (1.25 miles)
Type of Cable 50/125 µm or 62.5/125 µm multimode fiber
Wavelength 1310 nanometers
Launch Power (dBm avg.) Using 50/125 µm fiber:
Maximum: -14.0
Minimum: -22.5
Typical: -20.3
Using 62.5/125 µm fiber
Maximum: -14.0
Minimum: -19.0
Typical: -16.8
Input Optical Power (dBm avg.) Using 50/125 µm fiber or 62.5/125 µm fiber:
Minimum: -31.0
Maximum: -14.0
Table 2 Technical Specifications (continued)
